    OEM Reinforced Flexible Graphite Gasket Sheet Chemical Resistant

    Ask Lasest Price
    Brand Name : CLINGSEAL
    Model Number : CSG80
    Certification : ISO,SGS
    Price : 2.2USD PER KG
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 500Tons per month
    Delivery Time : 20 days
    • Product Details
    • Company Profile

    OEM Reinforced Flexible Graphite Gasket Sheet Chemical Resistant

    Products Description

    Custom OEM Flexible Graphite Gasket Manufacturing Solutions

    Advanced Material Engineering

    Our flexible graphite materials—comprising sheets, foil, paper, tape, and strips—are produced using proprietary chemical exfoliation and thermal expansion processes. Natural graphite flakes are transformed into worm - like structures with a bulk density of 0.003g/cc, then rolled into binder - free coils. This results in materials with 99.8%+ purity, engineered for precise OEM gasket manufacturing.

    Full - Cycle OEM Capabilities

    1. Custom Design & Prototyping
      • CAD/CAM engineering for complex gasket geometries (spiral - wound, corrugated, cut - to - size)
      • Rapid prototyping via laser/waterjet cutting (tolerances ±0.05mm)
    2. Material Hybridization
      • Composite solutions combining graphite with metals (stainless steel, tinplate) or polymers (PTFE)
      • Custom density ranges (0.8–1.5g/cm³) for specific pressure/temperature requirements
    3. Mass Production Efficiency
      • High - speed rolling lines producing 500+ meters of coils daily
      • Automated die - cutting for consistent gasket dimensions (widths 1000mm/1500mm)

    Key Performance Features

    • Chemical Resistance: Withstands acids (H₂SO₄), alkalis (NaOH), and organic solvents (e.g., methyl ethyl ketone)
    • Thermal Stability: Operates from - 200°C (cryogenic) to +1600°C (high - temperature furnaces)
    • Mechanical Properties: Compressive strength up to 70 MPa, elongation at break 8 - 12%

    Quality Assurance System

    • ISO 9001:2015 certified manufacturing processes
    • In - line testing for:
      • Density (ASTM D792)
      • Tensile strength (ASTM D638)
      • Gas permeability (ASTM D1434)
    • 100% visual inspection for surface defects

    Typical Applications for OEM Partners

    1. Industrial Equipment Seals
      • Custom gaskets for heat exchangers, pumps, and compressors
      • Reinforced designs for ASME BPVC Section VIII pressure vessels
    2. Automotive Components
      • Engine head gaskets with metal inserts
      • Exhaust system seals meeting automotive-grade thermal cycles
    3. Energy Infrastructure
      • Custom graphite rings for nuclear reactor coolant systems
      • Composite gaskets for LNG storage tanks (-162°C service)

    Value - Added Services

    • Private Labeling: Branded packaging and documentation
    • Logistics Support: Global shipping with DDP/EXW options
    • Technical Collaboration: FEA analysis for optimized gasket performance

    Case Study
    A leading European compressor manufacturer reduced warranty claims by 45% using our custom - designed graphite - metal hybrid gaskets, engineered for 150 bar pressure cycles.

    Contact Us
    Discuss your OEM requirements with our technical team. We provide free samples and 48 - hour turnaround on prototype orders.

    Trusted by 200+ global OEMs for mission - critical sealing solutions.
    Item Standard Value
    C concentration 99%
    S concentration <1000ppm
    chlorine concentration <45ppm
    tensile strength 4.5MPa
    compressibility >40%
    recovery >10%
    Temperature -200ºC-600ºC
    Pressure 20MPa
    Terence of Thickness -0.04mm~+0.04mm
    Terence of Dimension In accordance with your Gasket size
    Terence of Density -0.06~g/cm3+0.06gcm3

    Grades Separate :JB/T53392-1999
    Mechanical Data Qualified product Top Grade Superior Grade
    Density Tolerance
    g/cm3
    <0.4 ±0.10
    ±0.05
    0.4 ±0.07
    Tensile Strength MPa 3.2 4.5 5.0
    Compression Ratio % 35~55
    Rebound Rate % 9 11 12
    Stress relaxation rate % 10
    Ash % 6.0 3.0 1.0
    Heat loss on ignation % 450ºC 1.0 0.5
    600ºC 20 15

    Sulphur content
    1500ppm 1000ppm 600ppm

    Chloride content
    100ppm 50ppm 20ppm
