    Multi Layer Composite Graphite Sheet 99% For Rotating Equipment

    Ask Lasest Price
    Brand Name : CLINGSEAL
    Model Number : CSG80
    Certification : ISO,SGS
    Price : 2.2USD PER KG
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 500Tons per month
    Delivery Time : 20 days
    • Product Details
    • Company Profile

    Multi Layer Composite Graphite Sheet 99% For Rotating Equipment

    Products Description

    Multi-Layer Composite Graphite Sheet Solutions
    Our multi-layer composite graphite sheets are engineered using advanced lamination technology, combining flexible graphite materials with metal reinforcement layers. These composite solutions integrate the following components:
    • Flexible graphite core layers (sheets/foils/papers)
    • Stainless steel/nickel alloy reinforcement layers
    • Optional adhesive-free bonding process
    Manufacturing Process:
    1. Natural flake graphite undergoes chemical intercalation and high-temperature exfoliation to form vermicular structures (density ~0.003g/cm³)
    2. Expanded graphite is rolled into binder-free coils
    3. Composite sheets are produced via:
      • Pressure lamination with metal meshes
      • Vacuum-bonded multi-layer structures
      • High-temperature sintering processes
    Key Features:
    • Layered construction enhances mechanical strength
    • Maintains chemical resistance of pure graphite
    • Radiation shielding capabilities
    • Thermal stability (-200°C to +650°C)
    • Compression recovery up to 85%
    • Self-lubricating sealing performance
    Application Scenarios:
    1. Multi-layered packing rings for rotating equipment
    2. Composite gaskets for flange sealing in petrochemical plants
    3. Heat exchanger seals requiring structural reinforcement
    4. Aerospace-grade thermal insulation panels
    Composite Sheet Specifications:
    • Layer Configurations: 2-ply (graphite + metal) to 5-ply structures
    • Standard Sizes:
      • Width: 1000mm / 1500mm
      • Length: 30m / 50m (coils) / 1000x1000mm (sheets)
    • Thickness Range: 0.3mm-3.0mm (composite)
    • Density: 1.0-1.4g/cm³
    • Metal Layers: 0.05mm-0.2mm thickness
    Custom multi-layer composite graphite sheets available with:
    • Embedded wire mesh reinforcement
    • Corrosion-resistant coatings
    • Pre-cut gasket patterns
    • High-temperature adhesive options
    Item Standard Value
    C concentration 99%
    S concentration <1000ppm
    chlorine concentration <45ppm
    tensile strength 4.5MPa
    compressibility >40%
    recovery >10%
    Temperature -200ºC-600ºC
    Pressure 20MPa
    Terence of Thickness -0.04mm~+0.04mm
    Terence of Dimension In accordance with your Gasket size
    Terence of Density -0.06~g/cm3+0.06gcm3

    Grades Separate :JB/T53392-1999
    Mechanical Data Qualified product Top Grade Superior Grade
    Density Tolerance
    g/cm3
    <0.4 ±0.10
    ±0.05
    0.4 ±0.07
    Tensile Strength MPa 3.2 4.5 5.0
    Compression Ratio % 35~55
    Rebound Rate % 9 11 12
    Stress relaxation rate % 10
    Ash % 6.0 3.0 1.0
    Heat loss on ignation % 450ºC 1.0 0.5
    600ºC 20 15

    Sulphur content
    1500ppm 1000ppm 600ppm

    Chloride content
    100ppm 50ppm 20ppm
